CM09 Refrigerant Reclaim Machine

CM09 series refrigerant recovery&recycling machine is specially designed for removing moisture,acid and impurity from old and dirty refrigerant,it utilizes food grade material piston compressor with smart Siemens PLC control system to offer fast and deep reclaim rate based on CM 20 years compressor designed experience,the whole system specially designed according to AHRI740 standard, applied in various network which including screw chillers,commercial&industrial refrigeration system and freon manufacturing plant

Application:

Refrigerant purge

Features:

·Integrated functions of removing oil, acids and moisture including non-condensable gas.

·Oil less SS304 compressor for zero contamination

·Capable of handle most common refrigerants,like R22/R134A/R410A/R32 etc.

·Automatic oil drain&non-condensable gas discharge

·Over 99.8% refrigerant purity after recycling

·Once recovery&recycling process finished,machine stop working automatically

·Large wheels trolley design -- convenient for work site use;

·Overall protection device, safe credibility

·Controlled by Smart Siemens PLC programmer&touch screen

·Can be customized for flammable refrigerants

·Integrated of air cooling and water cooling

Specification:

Model	CM0901	CM0902	CM0903
Horsepower	4HP	10HP	25HP
Compressor Displacement	5m³/h	20m³/h	57m³/h
Compressor Type	Oil-free V-Twin reciprocating	Oil-free three-cylinder reciprocating	Oil-free twin-cylinder reciprocating
Reclaim Rate	≤60Kg/h	≤200Kg/h	≤300Kg/h
Refrigerant Purity	≥99.8%	≥99.8%	≥99.8%
Moisture	≤10 ppm	≤10 ppm	≤10 ppm
Acidity	≤1 ppm	≤1 ppm	≤1 ppm
High Boiling Residue	≤0.01%	≤0.01%	≤0.01%
Non-Condensable Gas	≤1.5%	≤1.5%	≤1.5%
Applicable Refrigerant	R22、R134a、R410A etc	R22、R134a、R410A etc	R22、R134a、R410A etc
Voltage	220V 50Hz 1Ph/380V 50Hz 3Ph	380V 50Hz 3Ph	380V 50Hz 3Ph

Please contact us by email ---->

Main Features And Advantages:

Oil less compressor

Over 99.8% purity after reclaimation

Utilize purify circulating design

Easy to do regular maintenance

Stainless steel compressor

Compatiable for various refrigerant

Can be customized for flammable refrigerant
