Storage tank gas recovery
Feature
·2-Stage compression reciprocating compressor
·Ultra fast recovery rate for vapor refrigerant
·Max working pressure 100Bar
·Capable of handling various refrigerant SF6/R23/R503/R508B etc.
·Equipped with chiller for deep refrigerant cooling
·Continuously running for 24 hours duty cycle
·CE certification
·High pressure shut-off device
·Special cooling system
Specification:
Model | CM-R23 |
Horsepower | 2HP |
Compressor Displacement | 1.5m³/h |
Compressor Type | SS304 oil-free reciprocating |
Vapor Recovery Rate | ≤15Kg/h |
Liquid Push&Pull Recovery Rate | ≤900Kg/h |
Cooling | Chiller |
Applicable Refrigerant | R23/SF6/R508B/R14/R508A/R116 etc. |
|
|
|
|
HP&LP Shut-off | Yes |
Max Working Pressure | 100Bar |
Power Source | 380V 50Hz 3Phase/220V 50Hz 1 Phase |
Certification | CE |
