CM8600（T）Dual System Refrigerant Charging Machine

CM8600 T series dual system refrigerant charging machine was specially designed for charging two different refrigerants and to be used in any kind of assembly lines of cooling system (refrigerators, water cooler,heat pump, air conditioners etc...) to perform evacuation, leakage test and refrigerant charging. This model equipped with 2 charging system allowed 2 charging gun work at same time. This model also have recovery function option which can recovery residual gas from refrigerant storage tank to avoid refrigerant waste.

Application

Water dispenser, Air Conditioner, Beer machine, Freezers, Refrigerators,Vehicle,etc.

Feature

·Siemens smart PLC technology for fast and accurate operation process

·Large colorful touch screen make the operation easy and simple

·High precision mass flowmeter technology ensures charging accuracy

·Powerful pneumatic booster pump for high speed charging rate

·The continuous charging quantity up to 99999g

·Automatic reminder function when the liquid supply tank is lack of refrigerant

·Combine vacuum, leakage inspection, refrigerant charging to all in one system

·Equipped with leakage alarm device

·High charging accuracy

Please contact us by email ---->

Main Features And Advantages

Smart linear algorithm ensure high charging accuracy

Require no daily charging accuracy calibration

-10℃~50℃ testing to ensure charging stability

Gas leakage detection monitoring

Smart Siemens PLC

CE certificate

Specification：

Model	CM8600 (T Series）
Serial No.	T100	T150
Charging speed	≥100 g/s	≥150-200 g/s
Single charge amount	10-999999g	10-999999g
Charging accuracy	Less than 500 g, ≤2 g 500 g-2000 g,≤±0.5% 2000 g,≤±0.3%
Measurement methods	RRT American Ruby Flow Meter
Resolution ratio	0.1g
Certificate	CE
Vacuum rate	4L/S	8L/S
Vacuum degree of machine	3-5pa
Charging gun port	Hansen 1/4 or 3/8 quick connectors
Length of charging gun	Standard with 3 meters, other specifications 3-10 meters optional
Communication interface	RS485/RS232/Ethernet
Channels quantity	100
Compressed air pressure	0.5-0.7Mpa
PLC	Siemens
Power supply	380V 50Hz 3Phase or 220V 50Hz 1Phase
Dimension	9008001340 mm
Approved refrigerants	R600a、R290、R32、R1234ze、R1234YF、R134A etc.
Application	Air Condition、Water Cooler、Beer Machine、Freezers, refrigerators, chillers, heat pumps,etc.
