CM8600 Series Single System Refrigerant Charging Machine

CM8600(ExT)series Dual System refrigerant charging machine is specially designed to charge flammable refrigerant fluid R32,R600A...etc to refrigeration system assembly line.it combines all in one in order to perform evacuation, leak test and refrigerant charges to meet the customers demand for affordable high precision and high quality based on CM smart controltechnology, the charging machine uses the well known Siemens Programmer giving the user a colourful and convenient touch interface,you set the data,let the machine complete the job for you

Application

Water dispenser, Air Conditioner, Beer machine, Freezers, Refrigerators,Vehicle,etc.

Feature

·Siemens smart PLC technology for fast and accurate operation process

·Large colorful touch screen make the operation easy and simple

·High precision mass flowmeter technology ensures charging accuracy

·Powerful pneumatic booster pump for high speed charging rate

·The continuous charging quantity up to 99999g

·Automatic reminder function when the liquid supply tank is lack of refrigerant

·Combine vacuum, leakage inspection, refrigerant charging to all in one system

·Equipped with leakage alarm device

·High charging accuracy

Please contact us by email ---->

Smart linear algorithm ensure high charging accuracy

Require no daily charging accuracy calibration

-10℃~50℃ testing to ensure charging stability

Gas leakage detection monitoring

Siemens PLC

CE certification

Specification：

Serial No.	S40	S60
Charging speed	≥40 g/s （2.4 kg/min）	≥60-80 g/s （3.6-4.8 kg/min）
Single charge amount	10-999999g	10-999999g
Charging accuracy	Less than 100 g, ±0.5 g 500 g-2000 g,≤±0.5% 2000 g,≤±0.3%
Measurement methods	RRT American Ruby Flow Meter
Resolution ratio	0.1g
Certificate	CE/ATEX
Vacuum rate	4L/S	8L/S
Vacuum degree of machine	3-5pa
Charging gun port	Hansen 1/4 or 3/8 quick connectors
Length of charging gun	Standard with 3 meters, other specifications 3-10 meters optional
Communication interface	RS485/RS232/Ethernet
Channels quantity	100
Compressed air pressure	0.5-0.7Mpa
PLC	Siemens
Power supply	380V 50Hz 3Phase or 220V 50Hz 1Phase
Dimension	9008001340 mm
Approved refrigerants	R134a,R410A,R22 etc.
Application	Air Condition、Water Cooler、Beer Machine、Freezers, refrigerators, chillers, heat pumps,etc.
